Supports survX, EGSTAR and GISTAR |  | 1280x720 dpi | | | Resistant to 1.5m fall |
 | The Most Advanced Mini Size GNSS Chip The BD940 is a triple frequency 336 channels receiver that delivers the quickest and most reliable RTK and RTX initializations for centimeter positioning. The BD940 reduces radiated emissions which speeds compliance certification and time to market. It provides assurance of long-term future-proofing and trouble-free operation. |
Multi-Constellations Under hash environment, K6 can still detect Multi-Constellations and have a fast initialization. After connecting to differential correction source, K6 can get centimeter accuracy. |  |
 | Laser Centering The laser transmitted from the bottom of K6 helps us find the right location for point collect and stakeout. |
Perfect for GIS In GIStar app, K6 can collect data along with its properties. And the small size and light weight makes K6 portable to collect GIS data in the fields. |  |
Unboxing and Operation Video: https://www.linkedin.com/pulse/how-does-kolida-k6-gis-data-collector-work-andy-lau
| Processor & Memory | ||
CPUOcta-core 1.5GHz | RAM3GB | |
| Built-in Storage Space32GB | Exterdable Storage Spaceup to 128GB | |
| Display | ||
Screen TypeCapacitive Touch Screen | Resolution1280x720 dpi | Size5.0 inches |
| User Interaction | ||
Operation SystemAndroid 5.1 | BluetoothYes, 4.0 | WifiYes |
| Built-in GPS 336 channels, GPS L1, L2, GLONASS L1, L2, BDS L1, L2, SBAS, L-band | Camera Yes, 8MP auto focus | Sim Card Supports 4G LTE, 3G WCDMA, 2G GPRS/EDGE |
Accuracy SBAS : 0.50m Horizontal 0.85m VerticalSingle base line RTK(<30km) : 0.008m±1ppm Horizontal 0.015m±1ppm Vertical | Internal Antenna Dual frequency | External Antenna Optional |
| Working Capability | ||
| Endurance 10 hours (7200mAh battery capacity) | OTG Function (Field Download) yes | Proof Level IP68 |
| Processor & Memory | ||
CPUOcta-core 1.5GHz | RAM3GB | |
| Built-in Storage Space32GB | Exterdable Storage Spaceup to 128GB | |
| Display | ||
Screen TypeCapacitive Touch Screen | Resolution1280x720 dpi | Size5.0 inches |
| User Interaction | ||
Operation SystemAndroid 5.1 | BluetoothYes, 4.0 | WifiYes |
| Built-in GPS 336 channels, GPS L1, L2, GLONASS L1, L2, BDS L1, L2, SBAS, L-band | Camera Yes, 8MP auto focus | Sim Card Supports 4G LTE, 3G WCDMA, 2G GPRS/EDGE |
Accuracy SBAS : 0.50m Horizontal 0.85m VerticalSingle base line RTK(<30km) : 0.008m±1ppm Horizontal 0.015m±1ppm Vertical | Internal Antenna Dual frequency | External Antenna Optional |
| Working Capability | ||
| Endurance 10 hours (7200mAh battery capacity) | OTG Function (Field Download) yes | Proof Level IP68 |
See more specs
1924
K6（BD940）data sheet 2019.pdf
PDF [4.827MB] download
