K3X

K3X

Models:K3X

The all new “X-Series” GNSS Engine and System-on-Chip structure design
X-Series

High Performance GNSS Engine

xian.jpg1760 Channels

All Constellation Signal Tracking

xian.jpg FarlinkBuilt-in UHF Radio Receiverxian.jpg0.69 kg

Ultra compact and Light



The Best-in-Class

GNSS Engine


The integrated advanced 1760-channel GNSS technology helps K3X to collect signal from GPS, Glonass, Beidou, Galileo, QZSS, in particular the latest BeiDou III. It greatly improved the data quality and satellite signal capturing speed of GNSS surveying.


Videohttps://www.youtube.com/watch?v=BIEyktshIgk

"SOC" ,

New System Structure


"SOC" means“System-on-Chip”, this new design integrates several individual hardware modules into one microchip. The receiver can be much lighter and smaller, system runs more stable and faster, bluetooth connection speed is faster. The“High-Low Frequency Integration”antenna can effectively restrain the interruptive signal


Constantly Ungraded

Inertial Measurement


KOLIDA’s 3rd generation inertial sensor and algorithm are onboard now. The working speed and stability have been improved for 30% from the last version. When the GNSS fixed solution is lost and recovered again, Inertial sensor can remain the working status in a few seconds, no need to spend time to reactivate it...


Tilt angle is up to 60 degrees, accuracy is down to 2cm.

0.69 kg,

Comfort Experience


K3X is ultra light, the total weight is only 0.69 kg including battery, 40% even 50% lighter than a traditional GNSS receiver. The light-weight design reduces surveyor’s fatigue, increase their mobility, is especially helpful to work in challenging environment.


Videohttps://www.youtube.com/watch?v=ldd9zRLPUBo


A Huge Leap

In Working Hours


Thanks to the high-capacity battery and the intelligent power management plan,  K3X can work up to 12 hours in RTK radio rover mode, up to 15 hours in static mode. The charging port is Type-C USB, users can choose KOLIDA quick charger or their own smartphone charger or power bank to recharge.


 Videohttps://www.youtube.com/watch?v=ckQNU4MS4uQ

Easy Operation


K3X can seamlessly connect to RTK GNSS networks via Android controller or smartphone with KOLIDA field data collection software, to work as a network rover, also can be worked as UHF radio rover by using its internal radio modem..


Videohttps://www.youtube.com/watch?v=zuxUCUZs_E4





New Radio,

Farlink Tech.


Farlink technology is developed to send large number of data and avoid data loss.


This new protocol improves the signal-catching sensitivity from -110db to -117db, so K3X can catch the very weak signal from a base station far way. (K3X's built-in UHF radio is receiver only)



Practical Functions


K3X employs Linux system, it helps surveyors to accomplish their missions easier, faster and more accurate by delivering exceptional quality and innovative features.




1

6a

New app.   New Productivity

Windows CE data controller is too old technology?

No problem. Simply use Ksurvey, Field Genius Android, SurvX App on your smart phone or tablet.

Enjoy the smooth operation of Android platform !


Post-processing Sw.   Free of Charge

KOLIDA GEO Office integrates

static data processing & Kinematic data adjustment



Satellite Tracking Ability

Channels1760 channels

Constellation

GPS, GLONASS, BEIDOU, GALILEO, QZSS, SBAS

MMS L-BandReserved
Positioning Output Rate1-50 HZInitialization Time7 s









Positioning Precision

UHF RTKHorizontal ±6mm +0.5 ppm
Vertical      ±10mm +1 ppm

Network RTKHorizontal ±6mm +0.5 ppm
Vertical      ±10mm +1 ppm

Static and Fast-Static

Horizontal ±2.5mm +0.5 ppm
Vertical      ±5mm +0.5 ppm


RTK Initial time

7s







User Interaction

Operation SystemLinux, System-On-Chip

Screen DisplayNo
wifiYes

Voice Guideyes, 8 language

Data Storage4 GB internal, 32GB external
Web UIYes
Keypad1 physical buttons







Working Capability

RadioBuilt-in receiver

Tilt Survey
Inertial Measurement
Electronic BubbleYes
Endurance

up to 15 hours (static mode), up to 12 hours (internal UHF rover mode)









Satellite Tracking Ability

Channels1760 channels

Constellation

GPS, GLONASS, BEIDOU, GALILEO, QZSS, SBAS

MMS L-BandReserved
Positioning Output Rate1-50 HZInitialization Time7 s









Positioning Precision

UHF RTKHorizontal ±6mm +0.5 ppm
Vertical      ±10mm +1 ppm

Network RTKHorizontal ±6mm +0.5 ppm
Vertical      ±10mm +1 ppm

Static and Fast-Static

Horizontal ±2.5mm +0.5 ppm
Vertical      ±5mm +0.5 ppm


RTK Initial time

7s







User Interaction

Operation SystemLinux, System-On-Chip

Screen DisplayNo
wifiYes

Voice Guideyes, 8 language

Data Storage4 GB internal, 32GB external
Web UIYes
Keypad1 physical buttons







Working Capability

RadioBuilt-in receiver

Tilt Survey
Inertial Measurement
Electronic BubbleYes
Endurance

up to 15 hours (static mode), up to 12 hours (internal UHF rover mode)









See more specs
