SL20

SL20

Models:SL20 REMOTE CONTROL SURVEY BOAT

Equipped with SDE-18S+ Scho Sounder System Water jet propulsion, Top speed 5m/s 14 kg, 105cm length Moon pool design
14 kg

Compact and Lightweight

xian.jpg105cm

Easy in Field Transportation

xian.jpg5m/sFast and Efficiencyxian.jpgMoon pool

Safe and Steady



Water Jet Propulsion:

Water Plant and Clash Proof


The driven system for SL20 is water jet propulsion, whose draught is much lower. Its performance would be much better against water plants, rubbishes, submerged rocks, shallow shore, etc.

"Moon Pool"

Anti-leakage Design


SL20 has a "moon pool" to contain equipment such as ADCP and echo sounder. The moon pool's diameter is up to 190mm. Instrument is separated from power supply, circuit and driven system of the boat, water won’t come into the cabin.

2


Better Sailing Attitude,

More Steady While Sailing


The bottom of the SL 20 boat is convex on the prow and stern, and concave in the middle. This special design keeps boat and the installed equipment more steady while sailing.

Easy Transportation,

One-man Operation


The SL20 boat weighs 14 kg, and is easier to carry by hands, and be transported by a small car.


Video Demonstrationhttps://www.youtube.com/watch?v=LUWM0jUDDAY

Physical

Hull MaterialCarbon Fiber

Hull Length105 cm

Hull Width55 cm

Weight (excl. ADCP)14 kgPayload10 kg
MotorWater jet propellerMoon Pool≤ 190 mm






Communication

Remote ControlRadio Frequency

Remote Control Frequency900 MHz / 868 MHzRemote Control Range Data2 km
Telemetry Frequency Data900 MHz / 868 MHzTelemetry Range2 km*2.4G wireless Ethernet as option, telemetry range 2km @ 2Mbps






Performance

Survey Speed Top2-5 knots (1-2.5m/s)

Speed Battery10 knots (5m/s)Endurance Battery2 hours @ 2.5m/s
Pack*

1 x 33V 40Ah,Quick Battery Replacement


*Higher capacity battery pack as an option








Options

Autonomous control


Real time video monitoring




SDE-18s Echo Sounder


ADCP telemetry module



Physical

Hull MaterialCarbon Fiber

Hull Length105 cm

Hull Width55 cm

Weight (excl. ADCP)14 kgPayload10 kg
MotorWater jet propellerMoon Pool≤ 190 mm






Communication

Remote ControlRadio Frequency

Remote Control Frequency900 MHz / 868 MHzRemote Control Range Data2 km
Telemetry Frequency Data900 MHz / 868 MHzTelemetry Range2 km*2.4G wireless Ethernet as option, telemetry range 2km @ 2Mbps






Performance

Survey Speed Top2-5 knots (1-2.5m/s)

Speed Battery10 knots (5m/s)Endurance Battery2 hours @ 2.5m/s
Pack*

1 x 33V 40Ah,Quick Battery Replacement


*Higher capacity battery pack as an option








Options

Autonomous control


Real time video monitoring




SDE-18s Echo Sounder


ADCP telemetry module



See more specs
