K5 IMU

K5 IMU

Models:K5 IMU

Inertial Measurement Technology, 555 channels, dual battery hot-swappable, a future-oriented productivity tool.
IMU

2cm/ 60° Tilt Survey Technology

xian.jpg555 Channels

All Constellation Signal Tracking

xian.jpg8 kmBuilt-in UHF Radio Working Rangexian.jpgDual Batteries

Hot-swappable & Extra Power Source


          440k5a

More Advanced

GNSS Engine

Featuring a powerful 555 channels GNSS mainboard inside, K5 IMU can track and process all the existed satellite constellations. With the utility of BEIDOU (COMPASS) signal, the data acquisition speed and GNSS signal stability are greatly improved from old generation

technology.


Work safer and easier

Thanks to the inertial measurement technology, K5 IMU allows user to do a tilt survey with a maximum tilt angle of 60 °. Centering is not a must, so surveyors can stay in safe position when they measure on motorway, and don't need to step into water .

         440k5a

Fast and accurate



Not like tilt sensor, Inertial Measurement Unit is no more affected by the earth's magnetic field and requires no correction. It can be activated and start working within only few seconds, this fast positioning will increase measurement speed by over 20%.


The combination algorithm of IMU + GNSS can get fixed solution faster and keep measurement results more stable, accuracy is down to 2cm.




Measure where others can't

Corner of wall? Points underneath pipe? Points occupied by car? These targets are no more accessible..




           440k5a



Long Range Radio Link


SDL400 built-in radio can send signal as far as 7 km in urban area, 8 km in suburban. The maximum coverage is up to 200 sq.km, suitable to have multiple rovers work simultaneously.




Barrier-Free

Measurement

In difficult environment you may lost connection with base station or VRS network. Don't be disappointed, you can choose from 3 creative work modes to continue surveying without interruption. (Repeater/ Router/ Mobile Refenrence Station)


         440k5a

Anti-interference


SDL400 built-in radio features anti-interference capability, so K5 IMU can work close to power plant, transformer substation, mobile signal tower and other interference source.



Practical Functions


K5 IMU employs Linux system, it helps surveyors to accomplish their missions easier, faster and more accurate by delivering exceptional quality and innovative features.




1

6a

New app.   New Productivity

Windows CE data controller is too old technology?

No problem. Simply download SurvX App on your smart phone or tablet.

Enjoy the smooth operation of Android platform !


Post-processing Sw.   Free of Charge

KOLIDA GEO Office integrates

static data processing & Kinematic data adjustment

Video Demonstration: https://www.linkedin.com/pulse/inertial-measurement-rtk-k5-imu-bring-your-productivity-andy-lau


Satellite Tracking Ability

Channels555

ConstellationGPS, GLONASS, BEIDOU, GALILEO, SBAS, QZSSMSS L-BandFunction preserved
Positioning Output Rate1Hz-50HzInitialization Time<10s









Positioning Precision

UHF RTKHorizontal ±8mm + 1 ppmVertical      ±15mm + 1ppm

Network RTKHorizontal ±8mm + 0.5ppmVertical      ±15mm+0.5ppmRTXHorizontal ±2cmVertical      ±5cm
Static and Fast Static

Horizontal ±2.5mm + 0.5ppmVertical      ±5mm + 0.5ppm


RTK Initialization Time


2-8s







User Interaction

Operation SystemLinux

Web UIYes
WifiYes
Voice Guide

Yes


Data Storage

8GB internal; up to 32GB external.







Working Capability

RadioBuilt-in emitting and receivingTypical working range 1-8km

Tilt Survey
Inertial Measurement
Electronic BubbleYes
Endurance

>14 hours (static mode), >10 hours (internal UHF base mode), >12 hours (rover mode)


OTG Function (Field Download)

yes


Other Function

Mobile Reference Station, Repeater, Router, CSD





Satellite Tracking Ability

Channels555

ConstellationGPS, GLONASS, BEIDOU, GALILEO, SBAS, QZSSMSS L-BandFunction preserved
Positioning Output Rate1Hz-50HzInitialization Time<10s









Positioning Precision

UHF RTKHorizontal ±8mm + 1 ppmVertical      ±15mm + 1ppm

Network RTKHorizontal ±8mm + 0.5ppmVertical      ±15mm+0.5ppmRTXHorizontal ±2cmVertical      ±5cm
Static and Fast Static

Horizontal ±2.5mm + 0.5ppmVertical      ±5mm + 0.5ppm


RTK Initialization Time


2-8s







User Interaction

Operation SystemLinux

Web UIYes
WifiYes
Voice Guide

Yes


Data Storage

8GB internal; up to 32GB external.







Working Capability

RadioBuilt-in emitting and receivingTypical working range 1-8km

Tilt Survey
Inertial Measurement
Electronic BubbleYes
Endurance

>14 hours (static mode), >10 hours (internal UHF base mode), >12 hours (rover mode)


OTG Function (Field Download)

yes


Other Function

Mobile Reference Station, Repeater, Router, CSD





See more specs
